Soup Spoon Mould

Soup Spoon Mould

Soup Spoon Mould have high quality, flexibility, mechanical properties and durability. Manufactured using hi-grade raw material, these products find wide application in various commercial and domestic sectors. The Soup Spoon Injection Mold that we offer are tested on set quality parameters.

This Soup Spoon Injection Mould is manufactured in our organization and is effectively managed by our team of talented professionals. Also, the widespread infrastructure is equipped with hi-tech amenities. At every stage of the Manufacturing of Plastic Soup Spoon Mould. We make sure our mould meets our predefined quality standards. Our Plastic Soup Spoon Mould. We customize this soup spoon mould according to client requirement by spoon size, spoon shape, spoon deep, spoon handle and spoon curves. After successfully making this soup spoon mould we test this mould in-house. When we are sure that this mould has all quality parameter standards that we predefine, we can start packaging to deliver this mould to you safely.

    • Technical Specification
    • Brochure
    • Inquiry
    • Request Call Back

      Call Us Now!

      OR

      Request CallBack

      +91 93777 61062
      +91 99248 77007

Technical Specification

Specification

Mould Name
Mould Size 500 X 500 X 280
Product Description PP/PS
Mould Cavity 18 to 24 cavity
Spoon Weight 2 to 2.5 gm
Suitable Machine 100 to 200 Tons
Mould Steel Core and Cavity P-20-2738 Prehard HRC32-38, Back Plate-C45
Heat Treatment HRC-32-38
Mould Life 60,00,000 shots
Mould Injection system Hot / Cold Runner bush
Mould Ejection system Ejection Pin
Mould Running Automatic / Manual
Mould Features 2 Plates moulds
Mould Injection Cycle Time 10.8 seconds
Delivery Time 30 Days for T1 Sample
Mould Surface Treatment Polish,Chrome, niteding

Key Features

Features

Precisely
Engineered

Anti
Corrosive

Long
Service Life

High Compressive
Strength

Effortless
Cleaning

Dimensionally
Accurate

Fully
Automated

Durable
Material

Easy to
Install

Low
Maintenance

Customization Options

Customization

Shape

Customize a mould according to the requirement of the shape of your spoon.

Handle

Customize a spoon mould according to the requirement of Long/Short Handle of your spoon

Scoop

Customize a mould according to the requirement of the Scoop of your spoon.

Cavity

Customize a spoon mould cavity after considering your production need & machine capacity.

Deep

Customize a mould according to the requirement of the Deep of your spoon.

Application

Make a custom mould according to different types of application of the spoon.

Branding on Spoon

If you would like to Print your Brand Name, Logo, Design, Text & whatever you like on the spoon, We can build a custom mould for you that will help make the product more beautiful.

Runner System Customization

We can customize Plastic Spoon Injection Mould by its Runner System – Surface Runner and Gate Design, Hot Runner and Three Plate Runner & Pin-Point Gate customization.

Mould Injection & Running

We can customize mould by Hot or Cold Runner Bush Injection System and also Customize a Mould Running System by Automatic or Manual Depends upon your Requirements.
